AAA Solenoid Controlled Pilot Air Valve ESO16PAO

AAA Products International - Part Number: ESO16PAO

| Subplate Mounted 1 1/2" Flow | Single solenoid, 2-position, spring return. Spool returns to position “C” when solenoid is de-energized. | Spool Configuration: Closed cross over, all ports are blocked in the center position. | Solenoid Operator Form: Intrinsically safe solenoid operator and coil with non-indicator, cord grip style DIN cap. | Valve Options: Locking manual solenoid override. | Valve O-Ring Option: Viton for body styles 2, 3 & 3P, Buna-N for body styles 4, 6, 8, 12, 4P, 8P &16P. | Please reference voltage: 24 volts - 60 hz, 120 volts - 60 hz, 240 volts - 60 hz, 6 volts D-C, 12 volts D-C, 24 volts D-C. |

If applicable, please confirm your required voltage:

24 volts, 60 Hz | 120 volts, 60 Hz | 240 volts, 60 Hz | 6 volts DC | 12 volts DC | 24 volts DC

Different O-ring materials (only applies to valve body O-rings) are possible for some models: -1 Neoprene for freon (-40°F to 225°F), -2 Silicon (-80°F to 400°F), -3 Viton for most aromatic gases (-20°F to 400°F, 600°F for short time). -4 Butyl Rubber (-60°F to 200°F). -5 Teflon (-250°F to 450°F). -7 Urethane, 70 Durometer (-65°F to 200°F). -9 Buna-N (-40°F to 250°F).
